Product Features:
- Type: Dual Flush
- Depth: 160mm
- Width: 570mm
- Height: 635mm
- Material: Plastic
- Finish: White
- Collection: Sigma
- Style: Modern
- Brand: Geberit
- Guarantee: 1 years
- Manufacturer Part Number: 109309005
- Cistern Lever Or Button Placement: Front
- Inlet Type: Centre, Back, Top
- Flow Pressure Range: 0.1 – 10 bar
- Maximum Operating Temperature of Water: 25 degree C
- Volume factory setting: 5.8 and 3 litre
- Cistern with front actuation only
- Suitable for concealed installation
- Fully insulated against condensation
- Protection cover for service opening can be mounted without tools and cut to length
- Dual flush with pneumatic and mechanical buttons and single flush with touchless flush or pneumatic buttons
- Can be reversed to give access from behind in a duct situation when flushed with HyTouch pneumatic buttons or touchless flush
- Flush valve features 6l and 4.5l flush settings to enable either a 6l and 3l flush or a 4.5l and 3l flush. For flush volumes of 4l and 2l a low flush beaker is required (241.894.00.1)
- Can be worked with used water (rainwater) provided it is passed through a filter system first
- Adjustable flushing volume
- Water supply connection at centre back or at the top
- Flush volume small range: 3-4 l and Flush volume factory setting: 5.8 and 3 1
